iFi - Zen Phono: MM/MC Phono Preamplifier Phono Preamps

DIMENSIONS

Lenght : 160 mm / 6.3 in

Width : 113 mm / 4.4 in

Height : 35 mm / 1.4 in

Weight : 515g / 1.14 Ibs

GENERAL

Gain settings : 72dB (+/- 1dB) 60dB (+/- 1dB) 48dB (+/- 1dB) 36dB (+/- 1dB)

Output Voltage : 20v RMS bal output into 100k (< 1% THD & N) 13.5V RMS bal output into 600R (< 1% THD & N)

Output Impedance(s) : 200 Ohm resistive 100 Ohm resistive

Input Impedance(s) : MM: 47K Ohms (Load: 110pF) MC High: 47K Ohms MC Low: 1K Ohms MC V Low: 110 Ohms

Signal to noise ratio : 94dB(A) MM re 2V BAL/1V UNBAL 80dB(unweighted 80kHz BW) MM re 2V BAL/1V UNBAL 84dB(A) MC Hi re 2V BAL/1V UNBAL 71dB(unweighted 80kHz BW) MM re 2V BAL/1V UNBAL 90dB(A) MC lo re 2V BAL/1V UNBAL 79dB(unweighted 80kHz BW) MC lo re 2V BAL/1V UNBAL 79dB(A) MC vlo re 2V BAL/1V UNBAL 69dB(unweighted 80kHz BW) MC vlo re 2V BAL/1V UNBAL

Equivalent Input Noise : -151dBV (A weighted) -141dBV (unweighted) -130dBV (A weighted) -119dBV (unweighted)

Power Supply Voltage : DC 5V / 500mA
