Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair
WHARFEDALE

Wharfedale EVO 4.2 Walnut Bookshelf Speakers Pair

Wharfedale EVO 4.2

Product not available

All products identified as « Clearance open Box » include products that are returned / exchanged within 10 days of purchase, as well as floor models. We do not sell any damaged, remanufactured or refurbished products. They are sold in new condition, in their original box *, with the full manufacturer’s warranty.

*There may be exceptions on rare occasions.

Beauty with purpose

The EVO4 cabinet is purpose designed from the ground-up. Not just the sleek curves, which stand out from the competition, but the materials, composites, internal bracing and damping too, for instance. All of this ensures the sonic character is not compromised by aesthetic. Quite the opposite, in fact.

Air Motion Transformer - AMT

Developed from the advanced AMT in ELYSIAN, EVO4’s Air Motion Transformer
treble unit utilizes a radically different way of moving air compared to the
conventional dome tweeter. A large, pleated lightweight diaphragm is driven across
its surface by rows of strategically placed magnets. Not only is this an efficient way
of moving air but it is also very accurate as the diaphragm is under close control
of the motor system at all times. The result is a wide bandwidth transducer that
achieves low distortion naturally and delivers wonderful musical detail

Dome Midrange

To match to the EVO4 AMT, Wharfedale has developed a fast and responsive
dome midrange with wide bandwidth thanks to the incorporation of a damped
rear chamber. This soft fabric dome, damped with a plasticizer coating, is vented
aperiodically into a specially shaped rear chamber that is profiled to scatter and
absorb rear energy from the dome. As a result this dome midrange features a
linear response from 800Hz to 5kHz, an astonishing bandwidth from such a unit.
Thanks to its high flux magnet, the EVO4 midrange dome also has a high efficiency,
ideally matched to that of the AMT, enabling it to respond easily and quickly to
the dynamics of the music fed to it. The wide dispersion of this dome and AMT
combination ensures that you’ll hear all the musical detail no matter where you sit

Bass

Utilizing the advanced, low distortion motor system developed for the ELYSIAN
bass units, EVO4 marries this to a woven Kevlar cone fitted with a low loss rubber
surround, giving a wide bandwidth driver which is equally adept at producing
powerful bass in addition to a natural lower midrange quality.
Like ELYSIAN, the bass units are loaded by the most advanced version of the
unique Wharfedale Slot Port yet. Christened SLPP (Slot Loaded Profiled Port) the
rear output of the bass units is not wasted. Instead the lowest frequency energy is
vented to a slot at the base of the speaker, specially profiled to equalize the high
internal pressure to the low pressure in the room.

Crossover

Combining the outputs of the drivers is an advanced computer modeled crossover
that has been developed over hundreds of hours of listening tests, fine tuned to
make sure that the blend between the drive units is seamless.
Crossover components have been specially chosen for their audio transparency and
feature high-grade polypropylene capacitors and laminated silicon-iron and air core
inductors, laid out to avoid electro-magnetic interference on a specially designed
circuit board.

Sound EVOlved

The new EVO4 represents the dawn of a new standard in hi-fi, from Wharfedale – the most famous name in British loudspeakers.

Following the concept of the best-selling EVO series that came.before it, EVO4 represents the evolution of affordable high-fidelity audio. More than just a new edition, EVO4 also fuses the EVO concept with trickle
down technology from the new flagship Wharfedale ELYSIAN series – and just like ELYSIAN, EVO4 pushes the boundaries of technology and performance of speakers within this price class. From the cabinet design to the materials employed in its distinct design, EVO4. stands head and shoulders above the competition.

Notably, the Wharfedale EVO4 series employs a specially engineered AMT (Air Motion Transformer) transducer for its proprietary, silky smooth high frequency reproduction. By design, the AMT allows for a higher volume of air to be moved during performance than with a convention soft dome tweeter. This higher-pressure action, encouraged by the principles of AMT design, offers an improved point-source HF reproduction with lower distortion properties than conventional tweeters. This is evident in the stunning and sheer clarity of the musical performance of all of the EVO4 series loudspeakers.

DIMENSIONS

Height : 455 mm / 17.9 inch(es)

Width : 250 mm / 9.8 inch(es)

Depth : (340+10) mm / (13.4 + 0.40 inch(es)

Weight : 13.4 kg / 6.1 lb(s)

DRIVER(S)

Bass Driver(s) : 6.5"(165mm) black woven Kevlar® cone

Midrange Driver(s) : 2"(50mm) soft dome

Treble Driver(s) : 30x60mm AMT

GENERAL

Type : 3-way bookshelf speaker

Transducer Principle : 3-way

Enclosure Type : bass reflex

Sensitivity : 87dB (2.83V @ 1M)

Power Amplifier(s) : 25-120W

Peak SPL : 105dB

Nominal impedance : 8Ω Compatible

Minimum impedance : 4Ω

Frequency Response : 54Hz ~ 22kHz (+/-3dB)

Bass Extension : 48Hz (-6dB)

Crossover Frequency : 1.4kHz,3.9kHz
